WRT60
6,000 lb. Capacity Walkie Rider Pallet Truck
Our 6,000lb capacity AC pallet truck has been designed to provide high productivity, reliability and low operating cost. Powered by a large AC drive motor that can propel the unit to 9mph, the WRT60 will allow operators to move more product per hour, and since there are no moving parts in the drive motor… many maintenance expenses are eliminated over the equipment’s lifecycle.
With its heavy duty steel construction and the use of best of breed non-proprietary parts the WRT60 delivers exceptional value. If you’re looking for a powered pallet truck that is tough and highly productive select our WRT60 for your facility.
| Vehicle Type | Motorized rider pallet truck |
| Capacity | 6,000lbs. @ 24″” load center |
| Power | 24 volt electric with ZAPI transistor controller-inverter |
| Max Lift Height | 8.25” |
| Collapsed Height | 3.25” |
| Fork Dimensions | 27” W x 46.75” L (length can be subject to change based on what is ordered) |
| Vehicle Dimensions | 36” W x 91.6” L (length can be subject to change based on what is ordered) |
| Turning Radius | 81.2” (27 x 48” forks |
| Travel Speed | Programmable with optional handset (0-9 mph empty / 0-6.5 mph loaded) |
| Battery Compartment | 31.12” x 13.12” x 31.62” |
| Battery Capacity | 510 AH Industrial Recommended |
| Charger | External industrial |
Product Highlights
- 24volt ZAPI AC transistor control
- Large high torque AC drive motor
- Heavy duty transmission
- Shaft mounted electromechanical brake
- Ergonomic handle with lift, lower, and infinitely variable speed control
- Ergonomic high-speed bar with lift, lower, horn, and high speed controls
- Safety reversing switch, dual horn controls, and tiller release brake
- Battery discharge indicator with hour meter
- Key switch to limit access to approved personnel
