P33

3,300 lb. Capacity Semi-Electric Pallet Jack

Our 3,300lb capacity semi-electric pallet truck can help to reduce operator strain caused by pulling or pushing loads on a manual hand pallet jack. Single speed powered travel is provided for both forward and reverse, while lifting and lowering is accomplished with a standard manual pump.

Vehicle TypeMotorized pallet truck with manual lift pumps
Capacity3,300lbs. @ 24” load center
Power24 volt electric with DC controller
Max Lift Height7.5”
Collapsed Height3”
Fork Dimensions27” W x 45” L standard
Vehicle Dimensions62” OAL, 27” OAW
Turning Radius56”
Travel Speed2.5mph empty, 2.0mph loaded
Battery CompartmentPolycase maintenance free
Battery Capacity30AH
ChargerInternal 110VAC plug-in

Product Highlights

  • 24 volt DC drive motor and controller
  • Electromagnetic disk brake
  • Ergonomic handle with safety reversing switch and horn
  • 30AH polycase batteries with internal 110VAC charger
  • Battery discharge indicator
  • US patent 754,415
